THE RACER
The SCALA 2 is the more heavy and robust version of the SCALA 2 light, which has been developed for hike and fly races like the Redbull X-alps. These are super long distance endurance competitions. The athletes need a wing that is not only superbly performing, but also is very easy in every matter. They need to trust the wing’s stability and safety when they are tired and not that concentrated.
The SCALA 2 is the evolution of the first version of the SCALA. We tuned on many screws to make it even better in performance, easyness and simplicity. The SCALA 2 is a high level EN C class wing!
With it’s high aspect ratio and performance the SCALA 2 stands out of the C class. It is a kind of game changer.
But even having that very elegant high aspect ratio, this wing is really easy in every matter! The outstanding feature is the extreme stable airfoil. As more turbulent it gets as more advantage you have with the SCALA 2!
SCALA 2 TECHNICAL FEATURES
The SCALA 2 light is an evolution of the SCALA light.
We improved the rigging system, allowing bigears, a higher load for bigger sizes and a better form stability.
The balooning has been optimized further on, as well we spend a lot of work in optimization of rod length, shape and number.
The SCALA 2 uses the superlight D10 cloth in bottomsail: so we gained a little weight reserve for more rods in topsail.
The airfoil and intakes have been slightly adapted to improve performance and handling.
-as well as the new riser and line attachments system is offering more control at max speed.
The SCALA 2 is made “on top” of the SCALA 2 light: more heavy and rigid cloth, longer and more rods: for even more performance.
SCALA 2 DESIGNER’S NOTE
We were very pleased with the high safety level of the SCALA 2 light. But we were even more pleased, that the “heavy version” of it: the SCALA 2 is still that safe and easy in extreme flying manoeuvres!
The new MJ 32 cloth is smooth, providing a really clean surface.
Hannes Papesh
SCALA 2 TECHNICAL DATA
| SCALA 2 | ||||||
| size | 18 | 19 | 20 | 21 | 23 | |
| number of cells | 78 | 78 | 78 | 78 | 78 | |
| projected span | m | 9,48 | 9,8 | 10,12 | 10,44 | 10,73 |
| projected area | m² | 17,71 | 18,95 | 20,2 | 21,48 | 22,73 |
| projected aspect ratio | 5,07 | 5,07 | 5,07 | 5,07 | 5,07 | |
| flat span | m | 11,8 | 12,20 | 12,6 | 13 | 13,37 |
| flat area | m² | 20,56 | 22 | 23,45 | 24,93 | 26,39 |
| flat aspect ratio | 6,77 | 6,77 | 6,77 | 6,77 | 6,77 | |
| line length | m | 6,95 | 7,19 | 7,43 | 7,66 | 7,88 |
| maximum chord | m | 2,28 | 2,36 | 2,44 | 2,52 | 2,59 |
| minimum chord | m | 0,11 | 0,11 | 0,116 | 0,12 | 0,12 |
| weight | kg | 4,59 | 4,76 | 4,9 | 5,05 | 5,2 |
| standard weight range | kg | 65-85 | 75-95 | 85-105 | 95-115 | 110-125 |
| extended weight range | kg | 95-100 | 105-110 | 115-120 | 125-130 | |
| certified weight range | kg | 65-85 | 75-100 | 85-110 | 95-120 | 110-130 |
| certification (EN/LTF) | C | C | C | C | C | |
| material | MJ 32, Skytex 40 | |||||
| risers | R12 | |||||
| riser length | mm | 540 | 540 | 540 | 540 | 540 |
| speedway | mm | 180 | 180 | 180 | 180 | 180 |
| price * | € | 5190 | 5190 | 5190 | 5190 | 5190 |
SCALA 2 RISERS
The SCALA 2 is delivered with the performance riser R12.
It has a differentiation for better control the wingtip at max speed.
It is furnished with pulleys and handles with magnet.
SCALA 2 COLORS
SCOPE OF DELIVERY
Glider, Harmonica concertina packing bag, repair material
SCALA 2 GUARANTEE
Like all other PHI wings, the SCALA 2 light is covered by the PHI PROMISE GUARANTEE.
Every damage is repaired in the first year of usage.
